【SLP二位二通微型系列直動式電磁閥（常開型）】-上海浦蝶閥門有限公司
二位二通常開型電磁閥,斷電打開,通電關閉;體積小,流量大,適用范圍廣,性能穩定 閥體材質為:鍛銅、SS316不銹鋼 環境溫度:0℃～65℃ 介質溫度:0℃～130℃ 安裝 :按閥上所標流向箭頭,為增強使用壽命和可靠性,最好線圈向上,水平安裝; 電壓：AC24V/110V/220V/230V/240V 50/60HZ DC24V/12V ±10%允許波動可選配德國NASS線圈 密封件:可采用NBR、VITON、EPDM等多種，以適用不同流體的開關控制  型號規格
接管
口徑 | 流量
通徑
mm | CV值 | 壓力差 | 最大
溫度
℃ | 線圈
配置 | 功率 | 線圈
等級 | 訂貨型號規格以下表中
型號規格電壓是220VAC | 重量
KG | 最小
壓力 | 最大工作壓力 | VA | W | 空氣
瓦斯 | 水、
熱水液體 | 輕油 | AC220V | DC24V | 閥體材料 | | 鍛銅 | 不銹鋼SS316 | | 1/8” | 1 | 0.04 | 0 | 30 | 30 | 25 | 80 | D | 22 | 13 | F | SLP2DF02N9A01 | SLP2DF02N5A01 | 0.4 | | 1 | 0.04 | 0 | 30 | 30 | | 130 | D | 22 | 13 | F | SLP2DF02E9A01 | SLP2DF02E5A01 | 0.4 | | 1 | 0.04 | 0 | 30 | 30 | 25 | 120 | D | 22 | 13 | F | SLP2DF02V9A01 | SLP2DF02V5A01 | 0.4 | | 1.5 | 0.09 | 0 | 20 | 20 | 15 | 80 | D | 22 | 13 | F | SLP2DF02N9AC2 | SLP2DF02N5AC2 | 0.4 | | 1.5 | 0.09 | 0 | 20 | 20 | | 130 | D | 22 | 13 | F | SLP2DF02E9AC2 | SLP2DF02E5AC2 | 0.4 | | 1.5 | 0.09 | 0 | 20 | 20 | 15 | 120 | D | 22 | 13 | F | SLP2DF02V9AC2 | SLP2DF02V5AC2 | 0.4 | | 2.5 | 0.2 | 0 | 15 | 15 | 12 | 80 | D | 22 | 13 | F | SLP2DF02N9AC3 | SLP2DF02N5AC3 | 0.4 | | 2.5 | 0.2 | 0 | 15 | 15 | | 130 | D | 22 | 13 | F | SLP2DF02E9AC3 | SLP2DF02E5AC3 | 0.4 | | 2.5 | 0.2 | 0 | 15 | 15 | 12 | 120 | D | 22 | 13 | F | SLP2DF02V9AC3 | SLP2DF02V5AC3 | 0.4 | | 3 | 0.25 | 0 | 12 | 12 | 10 | 80 | D | 22 | 13 | F | SLP2DF02N9A03 | SLP2DF02N5A03 | 0.4 | | 3 | 0.25 | 0 | 12 | 12 | | 130 | D | 22 | 13 | F | SLP2DF02E9A03 | SLP2DF02E5A03 | 0.4 | | 3 | 0.25 | 0 | 12 | 12 | 10 | 120 | D | 22 | 13 | F | SLP2DF02V9A03 | SLP2DF02V5A03 | 0.4 | | 3 | 0.3 | 0 | 6 | 6 | 5 | 80 | D | 22 | 20 | F | SLP2DF02N1A03 | SLP2DF02N3A03 | 0.46 | | 3 | 0.3 | 0 | 6 | 6 | | 130 | D | 22 | 13 | F | SLP2DF02E1A03 | SLP2DF02E3A03 | 0.46 | | 3 | 0.3 | 0 | 6 | 6 | 5 | 120 | D | 22 | 13 | F | SLP2DF02V1A03 | SLP2DF02V3A03 | 0.46 | | 4 | 0.4 | 0 | 5 | 5 | 4 | 80 | D | 22 | 13 | F | SLP2DF02N9A04 | SLP2DF02N5A04 | 0.39 | | 4 | 0.4 | 0 | 5 | 5 | | 130 | D | 22 | 13 | F | SLP2DF02E9A04 | SLP2DF02E5A04 | 0.39 | | 4 | 0.4 | 0 | 5 | 5 | 4 | 120 | D | 22 | 13 | F | SLP2DF02V9A04 | SLP2DF02V5A04 | 0.39 | | 1/4” | 1 | 0.04 | 0 | 30 | 30 | 25 | 80 | D | 22 | 13 | F | SLP2DF02N9B01 | SLP2DF02N5B01 | 0.39 | | 1 | 0.04 | 0 | 30 | 30 | | 130 | D | 22 | 13 | F | SLP2DF02E9B01 | SLP2DF02E5B01 | 0.39 | | 1 | 0.04 | 0 | 30 | 30 | 25 | 120 | D | 22 | 13 | F | SLP2DF02V9B01 | SLP2DF02E5B01 | 0.39 | | 1.5 | 0.09 | 0 | 20 | 20 | 15 | 80 | D | 22 | 13 | F | SLP2DF02N9BC2 | SLP2DF02E5BC2 | 0.39 | | 1.5 | 0.09 | 0 | 20 | 20 | | 130 | D | 22 | 13 | F | SLP2DF02E9BC2 | SLP2DF02E5BC2 | 0.39 | | 1.5 | 0.09 | 0 | 20 | 20 | 15 | 120 | D | 22 | 13 | F | SLP2DF02V9BC2 | SLP2DF02E5BC2 | 0.39 | | 2.5 | 0.2 | 0 | 15 | 15 | 12 | 80 | D | 22 | 13 | F | SLP2DF02N9BC3 | SLP2DF02E5BC3 | 0.39 | | 2.5 | 0.2 | 0 | 15 | 15 | | 130 | D | 22 | 13 | F | SLP2DF02E9BC3 | SLP2DF02E5BC3 | 0.39 | | 2.5 | 0.2 | 0 | 15 | 15 | 12 | 120 | D | 22 | 13 | F | SLP2DF02V9BC3 | SLP2DF02V5BC3 | 0.39 | | 3 | 0.25 | 0 | 12 | 12 | 10 | 80 | D | 22 | 13 | F | SLP2DF02N9B03 | SLP2DF02N5B03 | 0.39 | | 3 | 0.25 | 0 | 12 | 12 | | 130 | N | 22 | 13 | F | SLP2DF02E9B03 | SLP2DF02E5B03 | 0.39 | | 3 | 0.25 | 0 | 12 | 12 | 10 | 120 | D | 22 | 13 | F | SLP2DF02V9B03 | SLP2DF02V5B03 | 0.39 | | 3 | 0.3 | 0 | 6 | 6 | 5 | 80 | D | 22 | 13 | F | SLP2DF02N1B03 | SLP2DF02N3B03 | 0.45 | | 3 | 0.3 | 0 | 6 | 6 | | 130 | D | 22 | 13 | F | SLP2DF02E1B03 | SLP2DF02E3B03 | 0.45 | | 3 | 0.3 | 0 | 6 | 6 | 5 | 120 | D | 22 | 13 | F | SLP2DF02V1B03 | SLP2DF02V3B03 | 0.45 | | 4 | 0.4 | 0 | 5 | 5 | 4 | 80 | D | 22 | 13 | F | SLP2DF02N9B04 | SLP2DF02N5B04 | 0.38 | | 4 | 0.4 | 0 | 5 | 5 | | 130 | D | 22 | 13 | F | SLP2DF02E9B04 | SLP2DF02E5B04 | 0.38 | | 4 | 0.4 | 0 | 5 | 5 | 4 | 120 | D | 22 | 13 | F | SLP2DF02V9B04 | SLP2DF02V5B04 | 0.38 |
